SDLG EA7105H
Energy Saving
Electronically controlled high-pressure common rail engine with ECU-controlled fuel injection ensures high combustion efficiency and fuel economy for the 10-ton wheeled excavator. Electronic throttle with stepless speed regulation allows RPM to perfectly match working conditions. Efficient hydraulic components combined with optimized oil passage design reduce pressure loss for lower fuel consumption.
Convenience
Remote intelligent management system using 4G technology enables smart diagnostics and real-time vehicle status monitoring for the 10-ton wheeled excavator. Centralized maintenance components with externally routed filters enable "one-stop" servicing. Side panels and engine hood with wide-angle upward-opening design provide easy access for routine maintenance. Downflow air conditioning system simplifies filter cleaning and replacement.
|
Parameter |
Specification |
|
Total Weight |
9,200 kg |
|
Bucket Digging Force |
45 kN |
|
Swing Speed |
0 - 11 r/min |
|
Travel Speed |
30 km/h |
|
Max. Grabbing Radius |
7,921 mm |
|
Max. Digging Depth |
3,996 mm |
|
Max. Dumping Height |
5,475 mm |
|
Engine Power |
62.5 kW |
|
Max. Grabbing Capacity |
1,000 kg |
|
Overall Dimensions (L×W×H) |
6700 × 2270 × 2945 mm |
|
Max. Grabbing Height |
8,317 mm |
