ZJ105W Multi-functional Wheeled Excavator 1. Mobility: The wheeled chassis design allows the ZJ105W to travel quickly on roads, eliminating the need for trailers and enabling rapid movement between different construction sites, thus improving work efficiency. 2. Multi-functionality: It can be equipped with various attachments, such as buckets, grapples, and breakers, allowing one machine to perform multiple tasks including excavation, loading, demolition, and breaking, broadening its applicability. 3. Wide range of applications: Suitable for municipal construction, road engineering, pipeline construction, landscaping projects, and other fields, especially on paved roads or in situations requiring frequent movement, making it more suitable than tracked excavators.

Send Inquiry

Product Introduction

WhatsApp

ZJ105W Multi-functional Wheeled Excavator

1. Mobility: The wheeled chassis design allows the ZJ105W to travel quickly on roads, eliminating the need for trailers and enabling rapid movement between different construction sites, thus improving work efficiency.

2. Multi-functionality: It can be equipped with various attachments, such as buckets, grapples, and breakers, allowing one machine to perform multiple tasks including excavation, loading, demolition, and breaking, broadening its applicability.

3. Wide range of applications: Suitable for municipal construction, road engineering, pipeline construction, landscaping projects, and other fields, especially on paved roads or in situations requiring frequent movement, making it more suitable than tracked excavators.

WhatsApp

Item	Parameter	Item	Parameter
Model	ZJ105W	Max. Digging Reach	7500 mm
Operating Weight	9600 kg	Max. Ground-Level Digging Reach	7318 mm
Bucket Capacity	0.31 m³	Max. Digging Depth	3652 mm
Engine Model	Yuchai YC4FA85	Max. Vertical Digging Depth	3200 mm
Power	62.5 kW / 2200 rpm	Min. Swing Radius	2431 mm
Fuel Tank Capacity	147 L	Tail Swing Radius	2212 mm
Travel Speed	30 km/h	Max. Height at Min. Swing Radius	5866 mm
Swing Speed	12 r/min	Counterweight Ground Clearance	1094 mm
Gradeability	38°	Min. Ground Clearance	283 mm
Bucket Digging Force	39 kN	Wheelbase	2500 mm
Arm Digging Force	30 kN	Tire Width	510 mm
Hydraulic Pump Model	Load Sensing Variable Piston Pump (Electronic Control)	Arm Length	2200 mm
Max. Flow Rate	209 L/min	Boom Length	4000 mm
Working Pressure	24.5 MPa	Max. Attachment Dumping Height	6240 mm
Hydraulic Tank Capacity	140 L	Max. Attachment Lifting Capacity	800 kg
Transport Length	7153 mm	Max. Attachment Opening Size	1300 mm
Transport Height	2940 mm	Min. Attachment Opening Size	102 mm
Transport Width	2200 mm	Max. Attachment Lifting Height	8127 mm
Max. Digging Height	7931 mm	Max. Attachment Grabbing Height	7927 mm
Max. Dumping Height	5903 mm

WhatsApp

Reliable Construction Machinery Manufacturer

Shandong Zhongjue Heavy Industry Co., Ltd. is a professional manufacturer of construction and engineering machinery, integrating R&D, production, and global sales. Our main products include excavators, backhoe loaders, lawn mowers, road construction equipment, asphalt machinery, dredging robots, rebar processing equipment, as well as related spare parts. OEM and customized solutions are also available.
Our products are widely used in landscaping, agriculture, municipal engineering, water conservancy projects, and civil construction. With reliable quality and flexible supply capabilities, we have established wholesale and retail distribution channels in more than 200 countries and regions worldwide.We continuously provide cost-effective engineering equipment solutions to customers worldwide.
