Electric Loader

The Electric Loader is a new energy equipment designed for environmentally friendly heavy-duty operations. With a rated load capacity of 2,000 kg and a bucket capacity of 1.2 m³, this Electric Loader supports fast charging in 2 hours and provides up to 8 hours of continuous operation, balancing performance and sustainable operation needs. The bucket is made of Q690 high-strength wear-resistant steel with a curved design that reduces material residue and improves loading efficiency by 15% compared to traditional straight-edge buckets. It is suitable for handling various materials such as sand, gravel, coal, and construction materials.

The Electric Loader is equipped with an 80 kW permanent magnet synchronous motor, delivering smooth power output with zero emissions and low noise (operating noise ≤70 dB), making it ideal for indoor warehouses, municipal engineering, and other scenarios with high environmental requirements. It features hydraulic power steering and a pilot control system, with a lifting height of 3.5 m and a lifting speed of ≥0.8 m/s. Each loading-unloading cycle takes ≤25 seconds. The lithium iron phosphate (LFP) battery includes triple protection against overcharging, over-discharging, and short circuits, maintaining over 80% of its range even in low-temperature environments.

The control panel integrates battery level display and operational monitoring functions, along with overload warning and emergency power-off features. A single operator can efficiently perform the entire process of shoveling, lifting, and unloading. Widely applicable in logistics and warehouse handling, municipal waste transportation, and construction material markets, this Electric Loader reduces operating costs by 60% compared to fuel-powered models, making it an optimal choice for low-carbon operations.


Zhongjue Heavy Industry - Electric Loader Technical Specifications
