Standard Stationary Excavator
Introduction
The Standard Stationary Excavator is a specialized digging equipment designed for fixed areas such as mine shafts, port stockyards, and factory production lines. It offers exceptional stability and continuous operation capabilities to meet concentrated material handling needs. The machine body of the Standard Stationary Excavator is fixed using pre-embedded reinforced concrete or heavy steel structure bases, ensuring strong overall rigidity that can withstand reactive forces during excavation and prevent displacement.
The equipment is powered by high-power electric motors or diesel engines, with digging forces ranging from 5 to 50 tons depending on the model. Bucket capacities vary from 0.5 to 5 cubic meters, supporting 360° slewing operation. Some models of the Standard Stationary Excavator feature telescopic booms, achieving maximum working radii of 15-30 meters to cover large-area material excavation and transfer. The control system utilizes industrial-grade PLC programming, enabling both manual operation and integration with automated production lines for precise feeding and discharging, reducing manual intervention.
The design emphasizes durability, with key components made of wear-resistant alloy materials and equipped with dustproof and waterproof protection to adapt to harsh working environments. Remote monitoring and fault diagnosis capabilities are supported, lowering maintenance costs. The Standard Stationary Excavator serves as an efficient solution for large-scale, high-frequency material handling in fixed areas, widely applied in industrial production, mining, and other fields.
|
Model |
Power (kW) |
Working Weight (kg) |
|
ZJ80 |
30 |
400/500/600 |
|
ZJ95 |
37 |
750/900/1000 |
|
ZJ150 |
55 |
1200/1500/2000 |
Note: The above data is for reference only. Products can be customized according to user requirements.
|
Parameter Category |
Parameter Item |
Specification Value |
|
Main Parameters |
Base Height |
1.2M (adjustable per working conditions) |
|
Main Body Length |
3.3M |
|
|
Main Body Width |
2.3M |
|
|
Boom Length |
4.1M |
|
|
Arm Length |
2.4M |
|
|
Grabber Opening |
1.6M (standard) |
|
|
Tail Swing Radius |
2.3M |
|
|
Equipment Rotation Angle |
360° |
|
|
Grabber Rotation Angle |
360° |
|
|
Theoretical Energy Consumption |
35 kWh ±10% |
|
|
Control System |
Hydraulic Pilot Handle |
|
|
Working Capacity |
Max. Loading/Unloading Height |
6.6M |
|
Max. Loading/Unloading Range |
8.0M |
|
|
Max. Loading/Unloading Depth |
4.7M |
|
|
Max. Loading/Unloading Weight |
≤1500KG |
|
|
Theoretical Cycle Count (180°) |
2 times/min |
|
|
Work Process |
Motor Power (optional) |
45KW/55KW |
|
Hydraulic Pressure |
28MPA |
|
|
Platform Rotation Speed |
10.8RPM |
|
|
Total Weight |
6.1T ±5% |
|
|
Fuel Tank Capacity |
Hydraulic Tank Capacity |
160L |
